Fluidwell

Signal Inputs
‧4 (isolated) analog inputs.
‧3 digital status-/pulse inputs.
‧1 potentiometer input.
‧Modbus communication protocol (RS485 / RS232).
‧SDI-12 communication protocol.
Data outputs
‧GPRS data communication through TCP, FTP and/or email.
‧Full control through the web-portal or the Process View software.
‧Process alarms and system alerts by SMS.

Measuring range: 100 to 20.000mm
Output：Analog / Control
Power Supply：12 to 30V DC (reverse-polarity protected)
Accuracy：+/-3mm or 0.03% of measured distance
Enclosure： IP68 / NEMA6P

Input：Flowmeter / Status
Output：Pulse / Alarm / Control
Operating temperature / humidity：-20°C ... +60°C / 85% non-condensing, relative.
Power Supply：24V DC / 10 – 230V AC
Communication：RS232 or RS485 2-wire

Input：4 – 20mA input loop-powered
Power Supply：4 – 20mA, input Loop-powered
Ambient temperature of -40°C ... +70°C
Explosion Proof：ATEX

Input：Flowmeter / Temperature / Pressure
Output：Pulse / Analog
Ambient temperature：-40°C ... +80°C
Power Supply：Long life Lithium battery / 4 – 20mA Loop-powered / 8 – 24V AC/DC / 115 – 230V AC / Basic: 8 - 30V DC
Explosion Proof：ATEX

Input：4 ... 20mA
Output：Alarm / Analog
Ambient temperature：-40°C ... +70°C
Power Supply：Long life Lithium battery / 4 ... 20 mA Loop-powered / 8 ... 24 V AC/DC / 115 ... 230V AC
Explosion Proof：ATEX

Input：Flowmeter / Status
Output：Pulse / Analog
Ambient temperature：-40°C ... +70°C
Power Supply：Long life Lithium battery / 4 ... 20mA. Output loop-powered / 9 ... 27V DC
Explosion Proof：ATEX / IECEX / FM and CSA C-US
