Galltec HG80 Humidistat Series

Measuring element:Polyga®-measuring element
Measuring medium:Air / Pressureless / Non-aggressive
Control range:40 ... 90% RH
Operating temperatur: 0...60°C
Accuracy: > 50% RH(± 3.5% RH) / < 50% RH(± 4% RH)
Protection:IP50

Galltec KC.Ex / GC.Ex Humidity and Temperature Sensor with ATEX Certificate

Measuring element:Pt 100 class B
Measuring range:-20...+80 °C / 0 … 100%RH
Output:4...20 mA
Accuracy at 23°C:Humidity ±2%rh, other ranges ±0.3 K / Temperature ±0.2 K, other ranges ±0.3 K
Operating temperature:-40...+80°C
Degree of protection:IP65

Galltec TFG80 Humidity Temperature Sensor

Measuring medium:Air / Pressureless / Non-aggressive
Measuring range:0 … 100%RH
Measuring element:Pt100 ref. DIN EN 60751
Accuracy:±0.5°C / >40%RH(±2.5%RH) /

Galltec HGMini Room Humidistat series

Measuring element:Polyga®-measuring element
Water resistant control range:40...90%RH
Allowable ambient temperature:0...60°C
lifetime:> 6.000 breaking cycles
Protective system:IP20
