Level Transmitter

View:

VAL LC-LCT Explosion-Proof Continuous Float Level Meters

Output:4 ... 20 mA
Operating ambient temperature:-30/+55°C UR 90%.
Standard working temperature:up to 105°C
Maximum working pressure:50 Bar
Minimum degree of protection:IP65

FLUIDWELL TDR100 Continuous guided level radar with point level detection

Measuring range: 100 to 20.000mm
Output:Analog / Control
Power Supply:12 to 30V DC (reverse-polarity protected)
Accuracy:+/-3mm or 0.03% of measured distance
Enclosure: IP68 / NEMA6P

Dinel GRLM-70 Radar Level Meters

Measuring range:0.5 ... 40 m
Output:4 ... 20 mA s HART® / linka RS-485 / Modbus RTU
Accuracy:± 2 mm
Supply voltage:DC 18 ... 36 V / DC 18 ... 30 V / DC 18 ... 33 V
Ambient temperature range:-30 ... +70°C
Protection class:IP67

Dinel ULM-53 Ultrasonic Level Meters

Measuring range:0.1 ... 20 m
Output:4 ... 20 mA / 0 ... 10 V / RS-485
Accuracy:0.3% / 0.2% / 0.15%
Supply voltage:DC 18 ... 36 V / DC 18 ... 30 V
Ambient temperature range:-30 ... +70°C
Protection class:IP67 / IP68

Dinel HLM-35 Hydrostatic Level Meters

Working environment:no explosive hazard area
Supply voltage:12 ... 34 V DC / 12 ... 34 V DC
Output:4 ... 20 mA / 0 ... 10 V
Operating temperature range:-20 ... +70 °C
Protection class:IP67 / IP68

Dinel HLM-25S Hydrostatic Level Meter

Output:4 ... 20 mA / 0 ... 10 V
Supply voltage:12 ... 36 V DC / 16 ... 36 V DC
Ambient temperature range:-20 ... +70 °C
Accuracy:Typ. 0.5% of range / Max. 0.7% of range
Protection class:IP68

Dinel DLS-27 Capacitive Level Sensors

Output : NPN / PNP / NAMUR
Supply voltage : 7 ... 36 V DC / 7 ... 33 V DC
Current supply (state OFF / ON) : 3 / 10 mA
Max. switching current (NPN, PNP) : 200 mA
Temperature and pressure resistivity:-40°C ... +300°C / 0.1 ... 3 MPa
Protection class:IP67

Dinel DLM-35 Capacitive Level Meters

Output : 4 ... 20 mA (2-wire) / 0 ... 10 V (3-wire)
Supply voltage:9 ... 34 V DC / 12 ... 34 V DC
Ambient temperature range:-40 ... +85 °C
Pressure resistivity:0.1 ... 5 MPa
Protection:IP67 / IP68

Dinel CLM-36 Capacitive Level Meters

Output:4 ... 20 mA / 0 ... 10 V
Supply voltage:9 ... 36 V DC / 16 ... 36 V DC
Temperature durability:-40°C ... +300°C
Pressure durability:0.1 ... 7 MPa
Protection class:IP67 (Housing), IP65 (Connector) IP67

Huba 681 Pressure level transmitter

Medium:Fluides, aggressive fluides, potable water
Pressure range :0 ... 0.1 – 25 bar
Output :0 ... 5 V, 0 ... 10 V, 4 ... 20 mA
Accuracy :< 0.25% fs (< 0.05% fs on request)

CARLO Photoelectrics Level Sensor

Dinel ULM-70 Ultrasonic Level Meters

Measuring range:0.15 ... 20 m
Output:4 ... 20 mA / HART® / RS-485 with protocol Modbus RTU
Accuracy:0.15%
Supply voltage:DC 18 ... 36 V / DC 18 ... 30 V
Ambient temperature range:-30 ... +70°C
Protection class:IP67
