Features
● Real-Time data of temperature & humidity
● SUS304 metal housing
● Economic price, high accuracy, nicer long-term stability
● MEMS semiconductor sensor
● Anti-condensation protection
● Digital RS-485 output
● Compact size and elegant outlook and easy to install
Applications
Monitoring for HVAC process / Air conditioning / Environmental ventilation control / Building / Factory /Clean room / Laboratory / Storeroom / Crisper / Agriculture / Food industry / Machinery / Equipment
Specification
Input |
|
Temperature |
MEMS |
Humidity |
MEMS |
Measuring range |
|
Temperature |
0°C ... +50°C |
Humidity |
0 ... +100%RH (Non-condensing) |
| *The measurement range is defined at the standard condition(1013 mbar, 25°C). | |
Output |
|
Output |
RS-485 |
Signal connection |
3-wire |
Warm-up time |
< 2 min. stable time 20 mins. |
Response time |
t63 (15 ... 45°C/33 ... 75%RH)≦ 10 sec |
Sampling time |
About 3 sec |
Accuracy (at +25°C) |
|
Temperature |
±0.1°C (Suggest range : 10°C ... 50°C) |
Humidity (20 ... 70%RH) |
±1.0%RH |
Hysteresis error |
±1.0%RH |
Temp. influence |
±0.15%RH/°C (0 ... 50°C ) |
Electrical |
|
Power supply |
DC 24V±10% |
Current consumption |
DC：Max. 6 mA |
Electrical connection |
PVC cable 0.32 mm2 x 4C |
Environmental |
|
Medium |
Air |
Operating Temp. |
+0°C ... +50°C |
Operating Humid. |
0 ... 100%RH (Non-condensing) |
Storage temperature |
-20°C ... +60°C |
Installation |
|
Installation |
Flange ( Metal ) |
Protection |
|
IP rating |
IP24 ( Sensor )；IP 65 ( Body ) |
Electrical protection |
■ Polarity protection |
Certification |
|
Certification |
CE |
Material |
|
Housing |
SUS304 ( Metal ) |
Cable |
PVC |
Optional accessory |
Metal flange |
Weight |
|
Metal ( with cable ) |
135 g |
Download
Note : Design and specifications are subject to change without notice.
Note : Please make sure the product and the device which connect with RS-485 are on common ground, avoid damaged product.
