Features
● OEM Economic-Type Bulk Products
● Wide measuring range : -80 ... +20°C dew point, with fast response t90 < 20s
● Standardized installation : Universal 1/2″ G thread for easy integration and simple maintenance
● Interference resistance & reliability : EMC immunity, anti-condensation design, and low sensitivity to temperature variations ensure precise performance even in harsh environments
● Premium materials : Aluminum alloy housing, SUS304 probe, and SUS316 sintered filter for durability and corrosion resistance
● High consistency : Mixed-gas calibration and cyclic verification (IEC 61298 & ISO 17025 procedures) ensure measurement consistency with laboratory-grade equipment
● Wide measuring range : -80 ... +20°C dew point, with fast response t90 < 20s
● Standardized installation : Universal 1/2″ G thread for easy integration and simple maintenance
● Interference resistance & reliability : EMC immunity, anti-condensation design, and low sensitivity to temperature variations ensure precise performance even in harsh environments
● Premium materials : Aluminum alloy housing, SUS304 probe, and SUS316 sintered filter for durability and corrosion resistance
● High consistency : Mixed-gas calibration and cyclic verification (IEC 61298 & ISO 17025 procedures) ensure measurement consistency with laboratory-grade equipment
Applications
Compressed air system / Air separation equipment / Freezer / Adsorption machine / Plastic dryer / Industrial drying process / Paper / Chemical process monitoring
Specification
Input |
|
Input type |
Capacitive humidity sensor & Pt100 |
Operating range of dew point |
-80 ... +20 dp°C |
Output |
|
Max. scaling range |
Dew point: -80 ... +20 dp°C |
Output signal |
4 ... 20 mA+RS-485 (Standard) |
Signal connection |
3-wire |
Linear accuracy |
-60 ... +20 dp°C：±3 dp°C |
Load resistance |
Current output : ≦ 500 Ω |
Output calibrations (ZERO & SPAN) adjustment range |
Software |
Response time t90(Temp. at+25°C) |
＜20 sec |
Electrical |
|
Power supply |
DC 24 V±15% |
Current consumption |
DC 24 V, 50 mA |
Electrical connection |
M12 connector |
Environment |
|
Medium |
Air |
Operating Temp. for housing |
-40 ... +60°C |
Operating Humid. for housing |
0 ... 95%RH (Non-condensing) |
Operating Temp. for probe |
-40 ... +60°C |
Storage temperature |
-25 ... +60°C |
Installation |
|
Installation |
1/2″G |
Protection |
|
IP rating |
IP65 (Probe: IP20) |
Electrical protection |
■ Reverse polarity |
Material |
|
Housing |
Aluminum alloy |
Probe |
S.S.(SUS304) / SUS sintered filter(SUS316) |
Weight |
168 g |
Download
Note : Design and specifications are subject to change without notice.
Note : Please make sure the product and the device which connect with RS-485 are on common ground, avoid damaged product.
