Features
● Compact design and easy to install
● An economical choice, high C/P ratio
● Industrial class sensor comes with high accuracy and long-term stability
● An economical choice, high C/P ratio
● Industrial class sensor comes with high accuracy and long-term stability
Applications
Monitoring for HVAC process / Air conditioning / Environmental ventilation control / Environmental monitoring for building / Factory / Clean / Room / Laboratory / Monitoring for storeroom / Crisper / Agriculture / Food industry / Temperature and humidity measuring in machinery or equipment
Specification
Input |
|
Signal connection |
Capacitive Humidity Sensor & Pt100 |
Measuring range |
Temperature : 0 ... 50°C |
Recommended measuring range |
Temperature : 15 ... 35°C |
Output |
|
Output |
Temperature : RTD(Pt100 / NTC10K) |
Signal connection |
3-wire : Temp. / Humidity : (0 ... 10 V) |
Temp. influence |
0.2%RH/°C |
Load resistance |
0 ... 10 V；≧ 10 KΩ；4 ... 20 mA |
Output calibration(ZERO) adjustment degree |
10% of zero-point and full-range |
Response time(≧ 1m/s) |
＜20 s |
Accuracy |
|
Temperature |
±0.3°C+ 0.002°Cx tactual |
Humidity(at +25°C) |
±3%RH(30 ... 70%RH) of F.S. |
Humidity(at +15 ... 35°C) |
±5%RH(20 ... 80%RH) of F.S. |
Environment |
|
Measuring medium |
Air |
Storage temperature |
-5 ... +60°C |
Max. flow speed |
≦ 15 m/sec |
Electrical |
|
Power supply |
3-wire : DC 24 V ±20% |
Current consumption |
0 ... 10 V (3-wire) : 8 mA |
Electrical connection |
PVC Cable0.32 mm² x 6C |
Installation |
|
Fixed seat |
Flange installation |
Installation |
Probe type |
Protection |
|
IP rating |
IP24 |
Electrical protection |
■ Reverse polarity |
Certification |
|
Certification |
CE |
Material |
|
Housing |
PC fire-proof class(UL94V-2) |
Cable |
PVC |
Weight |
17 g (Without cable) |
Download
Note : Design and specifications are subject to change without notice.
Note : Please make sure the product and the device which connect with RS-485 are on common ground, avoid damaged product.
