Features
Measuring inputs：
LSE：signal inputs + AUX：0.2...2...20mA DC / AC ; 0.2...2...20V DC / AC
HSX：signal inputs：0.2...2...5A DC/AC ; 20...200...500V DC / AC
0.1% RDG basic accuracy
TRMS AC current and voltage measurements
20mA / 10V DC analogue output (optional)
RS485 serial communication port (optional)
Universal power supply：
18...60VAC/DC ; 90...260VAC/DC
Front protection degree：IP65
Please contact the sales for details.
LSE：signal inputs + AUX：0.2...2...20mA DC / AC ; 0.2...2...20V DC / AC
HSX：signal inputs：0.2...2...5A DC/AC ; 20...200...500V DC / AC
0.1% RDG basic accuracy
TRMS AC current and voltage measurements
20mA / 10V DC analogue output (optional)
RS485 serial communication port (optional)
Universal power supply：
18...60VAC/DC ; 90...260VAC/DC
Front protection degree：IP65
Please contact the sales for details.
Download
Note : Design and specifications are subject to change without notice.
Note : Please make sure the product and the device which connect with RS-485 are on common ground, avoid damaged product.
